2N Fortis Cylinder
The 2N Fortis Cylinder is a wireless electronic lock designed for secure, keyless access to residential apartments, including retrofits. It’s the final piece in 2N’s end-to-end access solution: fast to install, simple to manage, and enable residents to unlock all their doors with a single credential.
- Keyless access: from street, to suite
- Wire-free, hassle-free installation
- Expand your solution in minutes
Features & benefits
Versions
Technical Specifications
Power supply
| Battery life cycle | up to 80 000 openings (typically 2 years) |
| Battery | 2x CR2 3V |
Interfaces
| NFC | 132,56MHz |
| Bluetooth | 2,4GHz BLE |
| RFID | 13,56 MHz MIFARE® DESFire® (OSS-SO) |
Dimensions
| Mechanic knob diameter | 29mm |
| Mechanic knob length | 20mm |
| Electronic knob diameter | 40mm (outdoor version: 45mm) |
| Electronic knob length | 42,7mm (outdoor version: 44,8mm) |
| Cylinder length | From 26/26mm to 70/70mm (in 5mm steps from 30/30mm) |
Mechanical Properties
| Storage temperature | -40°C to 65°C |
| Knob material | Nickel-plated brass (hard plastic covers the antenna area) |
| Operating temperature | +5°C to 55°C (outdoor version: -25°C to 65°C) |
| Cover rating | IP55 (Outdoor version: IP66) |
Operational mode
| Supported mode | Offline |
Downloads
