Ares 12 LTE
Ares 12 LTE is an industrial unit for remote monitoring and alarming over LTE for locations without LAN access. Includes battery backup. Connect up to 14 external sensors and 2 dry contact detectors.
Ares 12 LTE monitors the readings of connected sensors.
When a value reaches the alarm threshold, the device sends an e-mail or a text message (SMS), or dials specified numbers. Use a SensDesk Technology portal to view measured data in a complex dashboard.
Ares 12 LTE includes an internal battery that provides back-up power for up to 24 hours.
Ares 12 LTE products support FOTA (Firmware Over The Air) for remote firmware updates.
Register as a partner to view pricing information and get exclusive access to our product catalog.
Register as Partner
Technical specifications
Protocols
| HTTP | No |
| HTTPS | No |
| DHCP | No |
| SNMP | No |
| SNMP trap | No |
| SNTP | Yes |
| SMTP | Yes |
| SMTP TLS | Yes |
| XML | Yes |
| HWg-Push (SensDesk) | Yes |
| MQTT | No |
| IPv6 | No |
| Modbus/TCP | No |
| Syslog | No |
| NB Push | No |
| Net-GSM (SMS GW) | No |
Sensors
| 1-Wire values | 14 |
| RS-485 values | 0 |
Alarms
| E-mail destinations: | 5 |
| E-mail templates: | Yes |
| SMS dest.: | 5 |
| SMS templates: | Yes |
| Trap destinations: | 0 |
| Group Alarm: | No |
| Alarm reminder: | Yes |
| Periodical status: | Yes |
| Alarm escalation: | No |
| IO over HTTP | No |
Interface
| Ethernet | No |
| WiFi | No |
| Mobile networks | LTE |
| Wiegand | No |
| 1-Wire | Yes |
| RS-232 | No |
| RS-485 | No |
Power and Dimentions
| Power supply (Jack) | Power supply: t9-30V, Consumption: 250mA |
| Power supply (Ethernet) | Power supply: 9-30V, Consumption: 250mA |
| PoE/48V | No |
| Operating environment | -5°C – 50°C / 20%RH – 80%RH |
| Storage environment | -25°C – 85°C / 5%RH – 95%RH |
| Dimensions | 98 x 92 x 33 (WxHxD) / 255g |
| Warranty | 24 months |
Type
| Environment | Industrial, SoHo |
| Installation | Rack, DIN, Table, Wall |
| IP Rating | IP40 |
| Housing | Metal |
Other
| Logger Scripts | 4Mb |
| SWITCH | No |
| Virtual Serial Port | No |
